D2|1.2379|SKD11

Category

Category Cold work tool steel
Delivery condition

Delivery condition Hot rolled&Hot forged,annealed to max.255HB
Supply form

Supply form Round bar,Flat bar,Sheet

Introduction:

AISI D2 steel is a high-carbon, high-chromium,tungsten-containing cold work tool steel. Its main alloying elements include carbon, siliconmanganese, chromium, and tungsten,while the phosphorus and sulfur contents are each limited to a maximum of 0.03%.
Equivalent grades of D2 cold work tool steel include:
·European/IS0:1.2601(X165CrMoV12),1.2379(X153CrMoV12).
·Japanese JIS:SKD11.
.Chinese GB:Cr12MoV/Cr12Mo1V1.

Chemical composition:

Corresponding international common brands				Hardness	Chemical Composition (%)
CHINA	US	JAPAN	GERMNAY	Hardness	C	Si	Mn	P	S	Cr	Ni	Mo	V
Cr12Mov	D2	SKD11	1.2379	-	1.4-1.6	0.1-0.6	0.1-0.6	≤0.03	≤0.03	11.0-13.0	-	0.7-1.2	0.5-1.1

Characteristics:

High-carbon, high-chromium (≈12%) steel designed for high-performance cutting tools.It offers better toughness than D3.
Nitridable.
Particularly suitable for air hardening.
Dimensionally stable.
High-carbon, high-chromium cold work tool steel.
The steel is smelt by EAF+LF+VD or EAF+LF+VD+ESR.
UT as per SEP 1921-84 D/d level,ESR material E/e level.
Nitridable,high-alloy steel for through-hardening with moderate machinability. Good tensile strength and wear resistance.
Good machinability and hardenability.
Better toughness than Cr12MoV.
Better size stability.

Applications:

High-duty cutting tools (dies and punches); blanking and punching tools; woodworking tools;
Shear blades for cutting light-gauge materials; thread rolling tools;tools for drawing, deep drawing, and cold extrusion; pressing tools forthe ceramics and pharmaceutical industries;
Cold rolls (working rolls) for multi-roll stands; measuring instruments and gauges;
Petrochemical and refinery equipment operating under high pressure and temperature
Small molds for the plastics industry where excellent wear resistance is required.

Mechanical Properties

Impact Toughness	Hardness	Poisson’s Ratio	Modulus of elasticity
77 J/cm2	62-63 HRC	0.27-0.30	190-210 GPa

Physical Properties

The physical properties can vary slightly depending on the specific composition and heat treatment of the D2/ DIN 2379/ AISI D2 steel. Its always recommended to refer to the manufacturer’s specifications for precise information.

Coefficient of thermal expansionat °C	20-100	20-200	20-300	20-400
10-6m/(m*K)	10.6	13.1	11.8	12.3

Thermal Conductivity at °C	20	350	700
W/(m*K)	16.7	20.5	24.2

Heat Treatment & Processes

01
Hardening

Heat the steel evenly to 820–840°C until the whole section reaches temperature. Then quench in oil to cool.
02
Normalizing

Heat the steel uniformly to about 900°C to achieve a normalized structure.
03
Annealing

Heat P20 steel to 770–790°C, hold it well at temperature, and then let it cool slowly inside the furnace.
04
Tempering

Heat the steel evenly and hold it for at least 1 hour per 25 mm of thickness at the chosen tempering temperature. Allow it to cool in still air.
